Product
Parameters
- Processor
- Linux: ARM Cortex-A7 Dual Core 1.0 GHz
Android: Quad core (4*2.0GHz A53)
- Memory
- Linux: 128MB RAM + 128MB ROM
Android: 1GB RAM + 8GB ROM,
2GB RAM + 16GB ROM(Optional)
- OS
- Linux
Android 13(Optional)
- Display
- 2.8-inch LCD display, resolution of 320 x 240
Capacitive Touchscreen(Optional)
- Buttons
- 10 x Numeric Keys
8 x Function Keys
1 x Power Button
- Audio
- Built-in Buzzer
- Communication
- Linux : CAT1 Or CAT1 + 2G(0ptional)
Andriod : 4G/3G/2G
Wi-Fi: 2.4G or 2.4G/5G(0ptional)
- Printer
- High-speed thermal printer, 80mm/s
Paper roll diameter: 40mm Paper
width: 58mm
- Magnetic Card Reader
- Triple track, bi-directional,
conforming to ISO 7810/7811/7813
- Smart Card Reader
- EMV L1/L2, conforming to ISO7816, 1.8V/3V/5V,
synchronous & asynchronous
- Contactless Card Reader
- EMV Contactless L1, conforming to ISO14443
Type A/B, Mifare, Felica
- Interfaces
- 1 x Type-C USB
2 x SIM Card + 1 x SAM Card
- Power Adapter
- Input: 100-240V AC 50/60Hz
Output: 5.0V DC, 2.0A
- Battery
- Li-ion battery, 3.7V/4000mAh/14.8Wh
- Environment
- Operating Temperature: -10°C to 50°C
Storage Temperature: -20°C to 70°C
Humidity: 10% to 90% (Non-Condensing)
